▶ Home > Product > Vehicular Antenna


가원인터내셔널(주)

- SPECIFICATION
VSWR : 3.5:1
Frequency Range : 30-88 MHz
Power Handling : 75 Watts
Gain : -5 to 0dB
Polarization : Vertical
Impedance : 50 Ohms
Radiation : Omnidirectional
RF Connector : BNC Female
Weight : 11 lbs (4.95Kg)
Overall Length : 10.5 feet (3.2m)
Environmental and Mechanical : Designed to meet the rigorous, environmental,
and mechanical conditions expected in a combat environment.

NSN : 5985-01-253-6137
- SPECIFICATION
Military Nomenclature : AS-3885/TRC 191
NATO Stock No. : 5985-01-253-6137
VSWR : 2.5:1
Frequency Range : 30-88 MHz
Power Handling : 75 Watts
Gain : -6 to -1dB
Polarization : Vertical
Impedance : 50 Ohms
Radiation : Omnidirectional
RF Connector : BNC Female
Weight : 11 lbs (4.95Kg)
Length : 10.5 feet (3.2m)
Environmental and Mechanical : Designed to meet the rigorous,
environmental, and
mechanical
conditions
expected in a
combat
environment.
